Question:

In the figure, Vo is the potential barrier across a p-n junction, when no battery is connected across the junction

(a) 1 and 3 both correspond to forward bias of junction

(b) 3 corresponds to forward bias of junction and 1 corresponds to reverse bias of junction

(c) 1 corresponds to forward bias and 3 corresponds to reverse bias of junction

(d) 3 and 1 both correspond to reverse bias of junction



Solution:

(b) 3 corresponds to forward bias of junction and 1 corresponds to reverse bias of junction
