What Are Quantum Numbers?

The circular path in which an electron revolves around the nucleus is called an orbit, and orbit is just another name for shell — the two terms mean the same thing. To locate an electron inside an atom precisely, we need a set of numbers that tell us which shell, which subshell, and which orbital it belongs to. These numbers are called quantum numbers — think of them as the electron's address.

What Is the Hierarchy Inside an Atom?

Before looking at each quantum number individually, it helps to understand how an atom is structured, layer by layer:

• The actual place where an electron resides is called an orbital. An orbital can be represented as a box, and a maximum of two electrons can be placed in any single orbital.
• Many orbitals together form a subshell.
• Many subshells together form a shell.
• Many shells together form an atom.

A useful analogy: think of a shell as a building, a subshell as a floor within that building, and an orbital as a room on that floor. A student living in a room represents an electron in an orbital — so just as a student is found in a room, an electron is found in an orbital.

So, moving from the outside in: an atom contains several shells; inside a shell, you find subshells; inside a subshell, you find orbitals; and inside an orbital, you find electrons.

What Is the Principal Quantum Number (n)?

The first quantum number is the Principal Quantum Number, represented by small n. It tells us which shell (or orbit) the electron is in.

The value of n is always an integer: 1, 2, 3, 4, 5, 6, and so on. These are also represented using the English alphabet letters K, L, M, N — so 1 = K, 2 = L, 3 = M, and 4 = N.

• n = 1 is the first shell
• n = 2 is the second shell
• n = 3 is the third shell

Maximum electrons in any shell can be calculated using the formula:

Maximum electrons=2n2\text{Maximum electrons} = 2n^2Maximum electrons=2n2

Example: For n = 4, the maximum number of electrons is 2 × 4² = 32 electrons.

What Is the Azimuthal Quantum Number (l)?

The second quantum number is the Azimuthal Quantum Number, represented by small l. It tells us about the subshell — that is, the different types of subshells that can exist within a given shell.

Using the building analogy: if a shell is the building and a subshell is a floor, then the value of l tells you which "floor" (subshell) you're looking at.

The value of l can be 0, 1, 2, or 3, and each value is assigned to a specific subshell:

Since each orbital can hold a maximum of two electrons, the maximum electrons per subshell follow directly from the number of orbitals — 1 orbital in s (2 electrons), 3 orbitals in p (6 electrons), 5 orbitals in d (10 electrons), and 7 orbitals in f (14 electrons).

How l Depends on n

The value of l depends on n. Specifically, l ranges from 0 to (n − 1), and n is always greater than l.

Example (n = 4): l can take values 0, 1, 2, and 3 — meaning the n = 4 shell contains four subshells: s, p, d, and f. Adding up their maximum electrons (2 + 6 + 10 + 14) gives 32 electrons, which matches the 2n² formula for n = 4.

Example (n = 3): l can take values 0, 1, and 2 — meaning the n = 3 shell contains three subshells: s, p, and d. Adding up their maximum electrons (2 + 6 + 10) gives 18 electrons for the third shell.

What Is the Magnetic Quantum Number (m)?

The third quantum number is the Magnetic Quantum Number, represented by small m. It tells us about the orientation of the orbital in space — in other words, it gives each individual orbital its own numbering within a subshell.

The value of m depends only on l, and it ranges from −l to +l (including 0):

• s subshell (l = 0): m = 0 → this matches the single orbital in s.
• p subshell (l = 1): m = −1, 0, +1 → this matches the three orbitals in p.
• d subshell (l = 2): m = −2, −1, 0, +1, +2 → this matches the five orbitals in d.

What Is the Spin Quantum Number (s)?

The fourth quantum number is the Spin Quantum Number. It tells us about the spin and rotation of the electron.

Its value can only be +1/2 or −1/2. When two electrons occupy the same orbital box, one is assigned a spin of +1/2 and the other is assigned a spin of −1/2.

💡 Expert Tip: Of the two electrons that can occupy a single orbital, one always has spin +1/2 and the other has spin −1/2 — this pairing rule is the basis for how electrons fill orbitals.

Worked Examples: Identifying Orbitals Using Quantum Numbers

Example 1: Finding the Orbital from Given Quantum Numbers

Given: n = 4, l = 0, m = 0, spin = +1/2. Identify the orbital.

Only two numbers are actually needed to identify the orbital: n and l. Here, n = 4 and l = 0 (which corresponds to the s subshell). So the answer is the 4s orbital.

Example 2: Finding All Four Quantum Numbers from a Given Orbital

Given: The orbital is 4p. Write all four quantum numbers (n, l, m, and spin).

• n comes directly from the number in the orbital name: n = 4
• l corresponds to the p subshell: l = 1
• m can take any value from −1, 0, or +1 (depending on which of the three p orbitals is being described)
• Spin can be +1/2 or −1/2, assuming the orbital is filled with electrons

Quick Reference: All Four Quantum Numbers Together

To put it all together with an example: consider an atom with shells at n = 1 and n = 2. The n = 1 shell has only one subshell (s), since l can only be 0 there — so any electron in this shell has l = 0, m = 0, and a spin of either +1/2 or −1/2.

The n = 2 shell has two possible values of l — 0 and 1 — meaning it contains both an s subshell and a p subshell. An electron located in the p subshell of the n = 2 shell, for instance, would have n = 2, l = 1, and an m value of −1, 0, or +1, along with a spin of +1/2 or −1/2.

In short: n tells you the shell, l tells you the subshell, m tells you the orbital, and spin tells you whether the electron's rotation is clockwise or anticlockwise — and together, these four numbers fully define the location of any electron in an atom.
